This is the Futaba S3305 High Torque, Metal Gear Servo.
This servo can produce high-current draw from your batteries. If using NiMH or LiPo batteries, make sure they are capable of delivering sufficient amps.
FEATURES
Wide usage in cars and boats that require standard size, high torque servos Two ball bearings 3-pole motor Standard Futaba J style connector Metal gears One year warranty
INCLUDES
One Futaba S3305 High Torque Metal Gear Servo with 1.5" (39mm) diameter horn, 1.2" (32mm) 6 point horn, 4 eyelets, 4 rubber grommets, and 4 mounting screws
SPECIFICATIONS
Dimensions: 1.6 x 0.8 x 1.5" (1-9/16 x 16/16 x 1-1/2") (40 x 20 x 38mm) Weight: 1.7oz (1-11/16oz) (47g) Speed: 0.25 sec/60° @ 4.8V 0.20 sec/60° @ 6V Torque: 124 oz-in (8.9 kg-cm) at 6V 99 oz-in (7.1 kg-cm) at 4.8V
This is the Futaba S3306 High Torque/High Speed Servo for 1/5 Scale Cars.
FEATURES
Ideal steering servo for 1/5 scale vehicles High speed High torque Dual ball bearings Nylon gears One year limited warranty
INCLUDES
Futaba S3306 1/5 scale High Torque/High Speed Servo Two grommets Four screws Four eyelets Two White plastic servo horns (arms) 1- "X" 3.8" (98mm) diameter 1- "6-arm" 3.5" (88mm) diameter
SPECIFICATIONS
4.8V 6V Torque: 267 oz-inch (19.2kg/cm) @ 4.8V 333 oz-inch (24.0kg/cm) @ 6.0V Speed: 0.20 sec @ 60° 0.16 sec @ 60° Size- 2.6 x 1.2 x 2.3 in. (2-5/8 x 1-3/16 x 2-1/4") (66 x 30 x 57mm) Weight- 126g (4-7/16oz)(4.4oz) Output Shaft Diameter: 8mm
SAVOX AIR MEGA TORQUE CORELESS DIGITAL SERVO 32KG/0.14s@6.0V
Trust Savox for your large scale model with the new updated range of high performance servos from Savox, especially designed to handle the stresses of large scale flying whether it be jet, 3D, or scale.Improved torque ratings and low gear backlash provide the ultimate in precise accurate movement time after time. All SA servos come supplied with larger, longer servo horns and aircraft rubber mounting hardware to make your build as trouble free as possible.Spec Check:
Dimensions(mm): 40.3x20.2x45.0
Weight(g): 79.0
Speed(@6.0V sec/60): .14s
Torque(@6.0V oz-in): 32kg
Gear: Unique Steel
Bearing: 2BB
Case: Full Aluminum
25 Tooth Spline
Savox Digital Low Profile Servo 9.0Kg@6V
Whoever said that size doesn't matter was right! When talking about the SC1251MG we think about the saying "It's not the size of the dog in the fight, it's the size of fight in the dog." Combining full metal gears and amazing speed, the low-profile dimensions of this servo makes it perfect for any vehicle that is cramped for space or those looking to save additional weight. Savox SC1251MG Features:
Super high 4096 resolution and metal gears
Super light-weight
Coreless Motor provides high speed, incredible efficiency, and low power consumption than comparable servos
The aluminum case design not only looks good but also helps operation to remain cool and smooth
Ideal as a steering servo for 1/10 surface applications and in gliders and airplanes that have thin wing profiles
Spec Check:
Dimensions(mm): 40.8X20.2X25.4
Weight(g): 44.5
Speed(@4.8V sec/60): .10
Torque(@4.8V oz-in): 97.2
Speed(@6.0V sec/60): .09
Torque(@6.0V oz-in): 125.0
Gear: Metal
Bearing: 2BB
Case: Aluminum
25 Tooth Spline
Frequency: 250-333hz
Pulse Width Frequency: 1520
SAVOX JUMBO DIGITAL SERVO 35KG/0.15s@7.4V
Savox jumbo sized servos for all heavy duty applications such as 1/5th scale cars, large boats and aircraft. Built to handle load and power these 7.4v compatible, digital servos feature all steel metal geartrain, full ball bearings, heatsink case body and heavy duty horns and mounts. SV0235MG Spec Check:
Dimension: 65.8x30x57.4mm
Weight: 200g
Speed (sec/60°): @6.0v 0.18, @7.4v 0.15
Torque (kg/cm): @6.0v 28, @7.4v 35
Gears: Unique Steel
Bearing: 2BB
Case: Aluminium Heat Sink
SAVOX HI TORQUE DIGITAL SERVO ALU CASE 30KG/0.13s@6.0V
Trust Savox for your large scale model with the new updated range of high performance servos from Savox, especially designed to handle the stresses of large scale flying whether it be jet, 3D, or scale. Improved torque ratings and low gear backlash provide the ultimate in precise accurate movement time after time. All SA servos come supplied with larger, longer servo horns and aircraft rubber mounting hardware to make your build as trouble free as possible. Spec Check:
Dimensions(mm): 40.3x20.2x37.2
Weight(g): 80
Speed(@6.0V sec/60): .13s
Torque(@6.0V oz-in): 30kg
Gear: Unique Steel
Bearing: 2BB
Case: Full Aluminum
25 Tooth Spline
Preiswertes Servo der = 23 mm-KlasseBekannt als "Monster"-Servo verwendet das HS-805BB ein sehr starkes Nylon-Getriebe mit einer robusten 8 mm Abtriebswelle. Das HS-805BB Analog-Servo überzeugt mit seinem dreipoligen Bürstenmotor, elastischen Nylonzahnrädern und zwei Kugellagern an der Abtriebswelle. Das drehmomentstarke HITEC Servo HS-805BB ist ideal für fast jedes große Flugzeug, große RC-Cars, LKWs oder Schiffe.Features: • Preiswertes "Monster" Analog Servo• Hohes Drehmoment• Nylon-Getriebe• 2 Kugellager
